Hydraulic cylinder mounting types

In the JIS B 8354 standard, the installation types of hydraulic cylinders are usually represented by specific codes. These codes are used to describe the installation methods of hydraulic cylinders, which helps users choose the right cylinder for their application needs. Different installation methods are suitable for different working conditions and installation requirements, so understanding these codes is very important. For example, some types of installation are suitable for fixed installations, while others are designed to allow movement or adjustment within a certain range.

These codes usually reflect the way the hydraulic cylinder is mounted, such as whether it uses a foot mount, flange, clevis, or other types of mounts. Each installation method has its unique structural characteristics and applicable scope, so correctly identifying and choosing the installation type of the hydraulic cylinder is crucial for ensuring the effective operation and longevity of the hydraulic system.

In practical applications, it is very important to choose the appropriate type of hydraulic cylinder installation based on the design and operating conditions of the machine. Using the codes in the JIS B 8354 standard can help users more clearly and accurately identify and select the appropriate hydraulic cylinder, thereby enhancing the performance and reliability of the machine.
